Description
STANDARD FEATURES
■ 202 racks per hour
■ Opti-RinSe™ system
■ Rapid Return Conveyor Drive Mechanism
■ Insulated hinged double doors with door
interlock switches
■ 19.5 inch chamber height opening
■ Top mounted micro-processer control module
■ Energy saver mode
■ Dirty water indicator
■ Low temperature alert
■ Conveyor dwell
■ Delime notification
■ Service diagnostics
■ NAFEM Data Protocol compliant
■ Computational Fluid Dynamic Designed Self-
Aligning Wash Manifolds
■ Stainless steel debossed anti-clogging wash
arms
■ Removable Integrated Pump Intake Screen
■ Stainless steel self-draining pump and impeller
■ Single, sloping scrap screen and deep basket
■ Stainless panels enclose perimeter and bottom
■ Door actuated drain closure
■ Single point electrical connection (three phase
only), does not include the booster heater
■ Convertible hot water or low temp final rinse
■ Vent fan and booster heater control
DIRECTION OF OPERATION
❑ Right to Left
❑ Left to Right
VOLTAGE
❑ 208/60/1 ❑ 240/60/1 ❑ 380/60/3
❑ 208/60/3 ❑ 240/60/3 ❑ 480/60/3
❑ 600/60/3
OPTIONAL EQUIPMENT AT EXTRA COST:
Stainless steel pressureless booster heater. Stainless steel vent
hoods with vent stack and locking-type damper. Higher than
standard chamber. Side loaders and unloaders. Floor mounted
steam booster. 193⁄4″ x 193⁄4″ peg, combination and miscellaneous
racks. Table limit switch. Drain water tempering kit.
